Rodless Pneumatic Cylinder
In environments where space efficiency and contamination control are critical—such as pharmaceutical packaging lines or food-grade conveyor systems—this rodless pneumatic cylinder redefines motion control with its magnetic-coupled design.
- Product Introduction
Compact Magnetic-Coupled Actuator for Space-Sensitive Automation
In environments where space efficiency and contamination control are critical-such as pharmaceutical packaging lines or food-grade conveyor systems-this rodless pneumatic cylinder redefines motion control with its magnetic-coupled design. By eliminating mechanical linkages between the piston and slider, the actuator ensures leak-free operation and superior sealing, ideal for sterile or dust-prone settings. Available in bore sizes from 10 to 40 mm, it operates within a 0.12–1.0 MPa pressure range, achieving smooth motion at speeds up to 500 mm/s, perfect for high-speed labeling machines or precision medical device assembly.
The rod-free structure slashes installation space by 40% compared to traditional cylinders, while offering extended stroke lengths for applications like automated palletizing or electronic component sorting. Dual adjustable buffers at both ends dampen operational shocks, reducing wear in high-cycle tasks such as bottling or sheet metal stamping. The piston chamber's isolation from external sliders prevents debris ingress, a vital feature for woodworking dust environments or chemical processing plants.
Durability is reinforced through corrosion-resistant materials, capable of withstanding temperatures from -10°C to +60°C-suitable for frozen food handling or industrial drying tunnels. Standardized ports (M5×0.8, PT1/8) simplify retrofitting into legacy systems, while safety holding forces up to 880 N ensure stability in robotic welding or CNC tool clamping.
A standout feature is the magnetic coupling's ability to maintain precise alignment without physical contact, crucial for cleanroom robotics or optical sensor calibration. Field tests in pharmaceutical facilities show a 30% reduction in maintenance intervals due to the sealed design's resistance to particulate contamination.
By merging space-saving innovation with rugged reliability, this rodless pneumatic cylinder empowers industries to optimize floor space and operational hygiene. Its adaptability across temperature extremes and demanding cycles makes it a cornerstone of modern automation, where efficiency and cleanliness drive productivity.
